DDR5 SPD EEPROM With Hub Built-In Temperature Sensor S-34HTS08AB

This IC is a DDR5 Serial Presence Detect EEPROM with Hub function (SPD5 Hub) built in temperature sensor.
The Hub feature allows isolation of a local bus from a controller host bus. This IC contains 1024 bytes (8K-bit) of EEPROM arranged as 16 blocks of 64 bytes (512 bit) per block. Each block can be write protected via software command. Page write and sequential read are available. This IC operates with 1.8 V VDDSPD and 1.0 V VDDIO and the SidebandBus (I2C & I3C) at 12.5 MHz maximum.

Caution
This product is intended to use in general electronic devices such as consumer electronics, office equipment, and communications devices. Before using the product in medical equipment or automobile equipment including car audio, keyless entry and engine control unit, contact to ABLIC Inc. is indispensable.

Features

JEDEC standard compliant
SPD5118
Two-wire I2C or I3C bus serial interface
Operation voltage range (VDDSPD)
1.7 V to 1.98 V
Operation voltage range (VDDIO)
0.95 V to 1.05 V
Operation frequency
I2C: 1.0 MHz max. (VDDSPD = 1.7 V to 1.98 V)
I3C: 12.5 MHz max. (VDDSPD = 1.7 V to 1.98 V)
1.0 V Push Pull I/O levels
1.0 V and 3.3 V Open Drain I/O levels
Operation temperature range
Ta = −40°C to +125°C
Operation temperature range (NVM Write Operation)
Ta = -40°C to +95°C

EEPROM

Page write
16 bytes / page
Sequential read
Write protect function during low power supply voltage
Write protect
Individual software data protection for each of 16 blocks of 64-bytes per block
Endurance
105 cycle / word*1(Ta = -40°C to +95°C)
Memory capacity
8 K-bit
Initial delivery state
FFh

Temperature sensor

Temperature accuracy
0.5°C typ. (Ta = +75°C to +95°C)
1.0°C typ. (Ta = +40°C to +125°C)
Temperature sample rate
8 samples / s min.
hysteresis width
1.0°C

Hub Function

Interfaces to I2C/I3C buses which have multiple devices on a shared bus
Uniquely addressed with fixed addressing on the same bus.
All Hubs respond to specific predefined I2C/I3C device select codes on a host interface bus
Integrates a second local I2C/I3C bus and passes through of commands from host bus onto local bus for addressing of I2C/I3C devices on local bus

Overall

Current consumption
EEPROM in standby mode and temperature sensor in active mode: 0.15 mA max.*2
EEPROM in read operation mode and temperature sensor in active mode: 2.0 mA max.*2
EEPROM in write operation mode and temperature sensor in active mode: 3.0 mA max.*2
Noise suppression
Schmitt trigger on input pins (HSCL, HSDA, LSDA)
Noise filter on input pins at I2C (HSCL, HSDA)
Packet Error Check (PEC) function
Parity Error check function
In Band Interrupt (IBI)
Bus Reset function
Up to 8 unique addressing
9-pin thermally enhanced DFN package

*1. For each address (Word: 8-bit)
*2. VDDSPD = 1.8V
