Automotive, 125°C Operation, 36 V Input, 500 mA, Voltage Regulator with Reset Function S-19318 Series

DatasheetJun. 11, 2024

Bulk download

Download a zip file of all documents related to this product.

Parts List

Distributors

Related articles

Stabilized power ideal for automotive devices S-19317/8, S-19311/2 Series

Stabilized power ideal for automotive devices S-19317/8, S-19311/2 Series

Product OverviewProduct Overview Standard Circuit ExampleStandard Circuit Example TO-252-9S (VA009-A)TO-252-9S (VA009-A) HSOP-8A (FH008-A)HSOP-8A (FH008-A)
Product Overview Standard Circuit Example TO-252-9S (VA009-A) HSOP-8A (FH008-A)

Output current : 500 mA (S-19318) ｜ 250 mA (S-19317)

This IC is a high-withstand voltage and low dropout positive voltage regulator with a reset function and has a built-in ON / OFF circuit, developed using high-withstand voltage CMOS process technology.
This IC operates at the maximum operation voltage of 36 V and a low current consumption of 3.0 μA typ. A built-in overcurrent protection circuit to limit overcurrent of the output transistor and a built-in thermal shutdown circuit to limit heat are included. Regarding a release signal output in the reset function, this IC enables delay time adjustment by an external capacitor.

Thermal simulation service
ABLIC Inc. offers a “thermal simulation service” which supports the thermal design in conditions when our power management ICs are in use by customers. Our thermal simulation service will contribute to reducing the risk in the thermal design at customers development stage.
For more information regarding our thermal simulation service, contact our sales representatives.

FIT rate calculation
ABLIC Inc. offers FIT rate calculated based on actual customer usage conditions in order to support customer functional safety design.
For more information regarding our FIT rate calculation, contact our sales representatives.

Caution: This product can be used in vehicle equipment and in-vehicle equipment. Before using the product for these purposes, it is imperative to contact our sales representatives.

Features

Regulator block

Output voltage
3.3 V, 5.0 V
Input voltage
3.0 V to 36.0 V
Output voltage accuracy
±2.0% (Tj = -40°C to +150°C)
Dropout voltage
100 mV typ. (5.0V output product, IOUT = 100mA)
Output current
Possible to output 500 mA (VIN = VOUT(S) + 1.0 V)*1
Input and output capacitors
A ceramic capacitor of 1.0 µF or more can be used.
Built-in overcurrent protection circuit
Limits overcurrent of output transistor.
Built-in thermal shutdown circuit
Detection temperature 170°C typ.
Built-in ON / OFF circuit
Ensures long battery life.

Detector block

Detection voltage
2.6 V to 4.7 V, selectable in 0.1 V step
Detection voltage accuracy
±2.0% (Tj = -40°C to +150°C)
Hysteresis width
0.12 V min.
Release delay time is adjustable*2
20 ms typ. (CDLY = 10 nF)

Overall

Current consumption
3.0 μA typ. (During regulator operation)
0.1 μA typ. (During regulator stop)
Operation temperature range
Ta = -40°C to +125°C
Lead-free (Sn 100%), halogen-free
Withstand 45 V load dump
AEC-Q100 qualified*3

*1. Please make sure that the loss of the IC will not exceed the power dissipation when the output current is large.
*2. The release delay time can be adjusted by connecting CDLY to the DLY pin.
*3. Contact our sales representatives for details.

Applications

  • Constant-voltage power supply and reset circuit for automotive electric component
