Automotive, 125°C Operation, 36 V Input, 40 mA Voltage Regulator with SENSE-input Reset Function S-19315 Series

Related products
S-19310(Monitors output voltage of built-in LDO voltage regulator)
S-19315(Monitors voltage at SENSE pin connection)
S-19316(Monitors input voltage of built-in LDO voltage regulator)

The S-19315 Series, developed by using high-withstand voltage CMOS process technology, is a positive voltage regulator with the reset function, which has high-withstand voltage and low current consumption.
Apart from the power supply pin, the detection voltage input pin (SENSE pin) is also prepared for the reset function, so the output is stable even if the SENSE pin falls to 0 V. The output form is Nch open-drain output.

Thermal simulation service
ABLIC Inc. offers a “thermal simulation service” which supports the thermal design in conditions when our power management ICs are in use by customers. Our thermal simulation service will contribute to reducing the risk in the thermal design at customers development stage.
For more information regarding our thermal simulation service, contact our sales representatives.

FIT rate calculation
ABLIC Inc. offers FIT rate calculated based on actual customer usage conditions in order to support customer functional safety design.
For more information regarding our FIT rate calculation, contact our sales representatives.

Caution: This product can be used in vehicle equipment and in-vehicle equipment. Before using the product for these purposes, it is imperative to contact our sales representatives.

Features

Regulator block

Output voltage
1.0 V to 5.3 V, selectable in 0.1 V step
Input voltage
3.0 V to 36.0 V
Output voltage accuracy
±0.03 V (1.0 V ≤ VOUT(S) < 1.5 V, Tj = −40°C to +125°C)
±2.0% (1.5 V ≤ VOUT(S) ≤ 5.3 V, Tj = −40°C to +125°C)
Dropout voltage
240 mV typ. (VOUT(S) = 5.0 V, IOUT = 30 mA)
Output current
Possible to output 40 mA (1.0 V ≤ VOUT(S) < 2.0 V, VIN = 4.0 V)*1
Possible to output 40 mA (2.0 V ≤ VOUT(S) ≤ 5.3 V, VIN = VOUT(S) + 2.0 V)*1
Input and output capacitors
A ceramic capacitor can be used. (1.0 μF or more)
Built-in overcurrent protection circuit
Limits overcurrent of output transistor
Built-in thermal shutdown circuit
Detection temperature 160°C typ.
Built-in discharge shunt circuit
Discharges output capacitor electrical charge during detector detection

Detector block

Detection voltage
3.0 V to 11.3 V, selectable in 0.1 V step
Operation voltage
3.0 V to 36.0 V
Detection voltage accuracy
±2.0% (Tj = −40°C to +125°C)
Hysteresis width selectable from "Available" / "Unavailable"
"Available": 5.0% ≤ VHYS ≤ 30.0% (Tj = −40°C to +125°C)
"Unavailable": VHYS = 0%
Output form
Nch open-drain output

Overall

Current consumption
During operation: 2.0 μA typ. (Tj = −40°C to +125°C)
During detector detection: 0.5 μA typ. (Tj = −40°C to +125°C)
Operation temperature range
Ta = −40°C to +125°C
Lead-free (Sn 100%), halogen-free
Withstand 45 V load dump
AEC-Q100 qualified*2

*1. Please make sure that the loss of the IC will not exceed the power dissipation when the output current is large.
*2. Contact our sales representatives for details.

Applications

  • Constant-voltage power supply and reset circuit for automotive electric component
  • Power supply and reset circuit for low-current battery-powered device
